Deploying a Claude agent runtime on Railway

Deploying a Claude agent runtime means shipping two things with opposite requirements. The API holds secrets, runs long jobs, and must fail closed. The landing site is public, cacheable, and holds nothing. Put them in one service and the strictest requirement wins in the wrong direction, because the thing that leaks is always the thing you were not thinking about.

This is the layout I run for Swarm 357 on Railway, and the mistakes that shaped it.

Two services, one project

The frontend never talks to the model provider. It talks to the API through a backend-for-frontend route on its own origin, which is the only place a write key is ever read.

The build-time secret leak

Here is the mistake that made me stop using an autodetecting builder.

A Next.js build inlines anything reachable from client code. If a builder injects all service variables into the build environment, and any code path touches the server key during prerender, the value can end up in the output bundle. Nothing warns you. The deploy is green. The key is in a JavaScript file served to every visitor.

The fix is to control the build yourself.

FROM oven/bun:1 AS builder
WORKDIR /app

# Only public configuration crosses into the build.
ARG NEXT_PUBLIC_SITE_URL
ARG NEXT_PUBLIC_API_URL
ENV NEXT_PUBLIC_SITE_URL=$NEXT_PUBLIC_SITE_URL
ENV NEXT_PUBLIC_API_URL=$NEXT_PUBLIC_API_URL

COPY package.json bun.lock ./
RUN bun install --frozen-lockfile
COPY . .
RUN bun run build

Two rules fall out of that file. Only NEXT_PUBLIC_ values are declared as build arguments, so nothing else can be inlined even by accident. And the server key is never an ARG at all, because it is read at runtime inside a route handler.

One Railway-specific trap: if your ignore file excludes the lockfile, --frozen-lockfile fails in a way whose error message points at dependencies rather than at the ignore file. Keep the lockfile in the build context.

The public demo is an abuse surface

A "try it live" box on a marketing site is an unauthenticated endpoint that spends money. Treat it that way.

Every control below is server-side, because client-side limits are suggestions:

• Force simulation. The backend-for-frontend pins simulate: true regardless of what the request body says. A visitor cannot ask for a live run.
• Clamp the budget. Whatever number arrives, it is clamped to the demo cap before it reaches the API.
• Cap the body size. Oversized requests get a 413 rather than being parsed.
• Bound the task length. A 500-character limit on the input, enforced on the server, with the same limit set on the textarea so the UI agrees with reality.
• Rate limit per IP. A sliding window returning 429.

The write key stays server-only. There is no public environment variable that carries it, and there should be no code path where a browser could obtain one.

Let the container decide server mode

Bash deny and human-in-the-loop approvals must fail closed in production. The brittle way to arrange that is an environment variable you set by hand in a dashboard, because the one deploy where somebody forgets is the deploy that matters.

Instead, the API image sets SWARM_SERVER_MODE and the server re-asserts it at import. Bash is denied unless SWARM_ALLOW_BASH=1, HITL is on for Bash, and Read and Write are confined to the workspace root. That posture comes from the artifact rather than from a checklist.

Authentication follows the same principle. SSE and write endpoints require SWARM_API_KEY when it is set, and production auth is fail-closed. Unauthenticated reads of run telemetry are redacted rather than blocked, so the public surface is useful without leaking task content.

Environment variables, sorted by where they are read

# API service, runtime
ANTHROPIC_API_KEY=sk-ant-...
SWARM_API_KEY=...
ALLOWED_ORIGINS=https://swarm357.techtideai.io

# Frontend, build time only
NEXT_PUBLIC_SITE_URL=https://swarm357.techtideai.io
NEXT_PUBLIC_API_URL=https://your-api-host

# Frontend, runtime only, never a build arg
SWARM_API_KEY=...

Keep local values in a gitignored .env.local. Never paste a key into a chat window, an issue, or a commit, and run a secret scanner over full git history in CI rather than trusting that you did not.

Deploying

railway link
railway up
railway redeploy --service api --yes

After the deploy, check the things that actually break:

1. /api/health responds and reports the version you expect.
2. The demo endpoint returns a simulated result, and a crafted request asking for a live run still returns a simulated one.
3. An oversized body returns 413, and a rapid loop returns 429.
4. No NEXT_PUBLIC_ variable contains a secret, and the client bundle does not contain the write key. Grep the build output for it once, so you know rather than assume.
5. CORS allows only the origins you listed.

Do not keep polling a cached version endpoint after the platform confirms the deployment. Run the manual truth test instead.

When Railway is the wrong host

• You need distributed rate limiting across replicas. The limiter is single-process, and stacking per-process caps is not the same guarantee.
• You have compliance requirements on data residency. Check the region story before you build on it.
• The workload is bursty and idle-heavy. A serverless runtime may cost less, at the price of cold starts that hurt long agent runs.

Follow the checklist

Read Railway deployment for the step-by-step, production checklist for the gates, Docker for the API image, and the security model for the posture the container enforces. For the runtime controls behind all of this, why your agent needs a bash policy gate covers the deny-by-default path.
